JBL BAR 500 – JBL Store Thailand
NZ฿ 1,000.00 NZ฿ 1,000.00SAVE 46%
JBL BAR 500
JBL BAR 500
JBL BAR 500
JBL BAR 500
JBL BAR 500
JBL BAR 500
JBL BAR 500
JBL BAR 500
JBL BAR 500
JBL BAR 500
JBL BAR 500
JBL BAR 500
JBL BAR 500
JBL BAR 500
JBL BAR 500
JBL BAR 500
JBL BAR 500
JBL BAR 500
JBL BAR 500
JBL BAR 500
JBL BAR 500
JBL BAR 500
Black
FREE SHIPPING
100%
AUTHENTIC PRODUCT
1 YEAR OFFICIAL
WARRANTY

Dolby Atmos® and MultiBeam™ 3D surround sound

Experience cinematic quality 3D surround sound, listen to stunning sound effects from every corner of the room. No additional surround speakers are required.

Dolby Atmos® and MultiBeam™ 3D surround sound

Experience cinematic quality 3D surround sound, listen to stunning sound effects from every corner of the room. No additional surround speakers are required.
<span>Powerful JBL Pro Sound</span>

Product Description

Movies, music or games? Bring your movies to life with 3D MultiBeam™ surround sound and Dolby Atmos® 3D, while PureVoice technology optimizes audio clarity so you don't miss a word. Experience exhilarating bass from a 10-inch wireless subwoofer, and with AirPlay, Alexa Multi-Room Music (MRM), and Chromecast built-in ™, you have over 300 easy streaming options to choose from. Whatever you need, the JBL Bar 500 is here to satisfy you.
General Specifications
Power supply
100 - 240V AC, ~ 50/60Hz
Networked standby power
< 2.0 W
Operating Temperature
0°C - 45°C
Audio Specifications
TOTAL SPEAKER OUTPUT POWER (MAX. @ THD 1%)
590W
SOUNDBAR OUTPUT POWER (MAX @ THD 1%)
290 watts
SUBWOOFER OUTPUT POWER (MAX @ THD 1%)
300 watts
Transducer of the soundbar
4x Racetrack Bits (46x90 mm) Tweeter 3x 0.75 inches (20 mm)
Subwoofer transducer
10 inches (260 mm)
Frequency range
35Hz - 20kHz (-6dB)
Audio input
1 X OPTICAL, TRUTH, USB (USB PLAYBACK IS SUPPORTED ON US MODELS FOR OTHER MODELS, USB IS FOR SERVICE ONLY)

Dimensions
Soundbar size (WxDxD)
1017 x 56 x 103.5 mm / 40 inches x 2.2 inches x 4 inches
Subwoofer size (WxDxL)
305 x 440.4 x 305 mm / 12 inches x 17.3 inches x 12 inches
Soundbar weight
2.8 kg / 6.2 lbs
Subwoofer weight
10 kg / 22 lbs
Package size (WxDxD)
1105 x 370 x 475 mm / 43.5 in x 14.6 in x 18.7 in
Gross Weight
16.2 kg / 35.6 lbs
Control and connection information
USB PORT
Type A
USB RATING
5V DC, 0.5A
Supported file formats
MP3
MP3 AUDIO CODEC
MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3
RANDOM RATE OF MP3
16 - 48 kHz
BITRATE OF MP3
80 - 320 kpbs
Bluetooth version
5.0
Bluetooth profiles
A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range
2400 MHz – 2483.5 MHz
Bluetooth is being transmitted.
<15 dBm (EIRP)
Wi-Fi networks
IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range
2412 - 2472 MHz (2.4 GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmission power
 < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range:
5.15 - 5.35GHz, 5.470-5.725GHz, 5.725 - 5.825GHz
Power of 5G Wi-Fi transmitter:
5.15-5.25GHz <23dBm, 5.25-5.35GHz & 5.47-5.725GHz <20dBm, 5.725-5.825GHz <14dBm (EIRP)
2.4G WIRELESS TRANSMITTER FREQUENCY RANGE:
2406 - 2474MH
POWER OF 2.4G WIRELESS TRANSMITTER:
＜10dBm (EIRP）
Video Specifications
HDMI VIDEO RECEIVER PORT
1
HDMI output information (with Enhanced Audio Return Channel, eARC)
1
HDCP VERSION OF HDMI
2.3
THROUGH HDR PLAYBACK
HDR10, Dolby Vision
What's in the box?
  • 1 x Soundbar
  • 1 x Wireless Subwoofer
  • Remote control with 2 x batteries
  • Power cord (up to 8 wires, depending on model)
  • 1 x HDMI cable
  • 2 x Shaped wall mount with screws
  • Getting Started Guide
  • Safety Manual and Warranty Card
  • Mold plate for wall mounting
Documents & Downloads

Features

Wireless subwoofer speakers
Size 10 inches

The thrilling and precise bass comes from this powerful 10-inch wireless subwoofer speaker, bringing action to the movie and the feel to your music.

Experience flawlessly clear dialogue.

JBL's PureVoice technology is powered by our unique algorithm. Improves speech clarity
Rest assured that you'll never miss an important conversation, even when listening to full surround effects.

Built-in Wi-Fi wireless connection function, support AirPlay, Alexa Multi-Room Music and Chromecast built-in™

Get ready to open up the world of entertainment! Access over 300 online music streaming platforms via AirPlay, Alexa Multi-Room Music and Chromecast built-in™.


Works with voice-activated speakers

Simply connect JBL Bar 500 to your voice-activated device and instantly instruct Alexa, Google Assistant or Siri to stream your favorite music to the soundbar.

HDMI eARC with Dolby Vision 4K image transmission

Enjoy uncompressed Dolby Atmos surround sound over the same HDMI cable with an HDMI eARC connection.

Optimize the sound
with all rooms

The JBL Bar 500's Easy Sound Calibration technology guarantees you the ultimate 3D Surround Effect.
No matter what kind of room you are in, the system will adjust the sound to suit the room conditions, providing a realistic listening experience like being in a movie theater.

JBL One App


Customize EQ and control all compatible speakers with one convenient application. Using the JBL One app, you can get help setting up your speakers, tweaking settings, and searching for included music services to easily find your newest favorite music.
