Enjoy movies, music and games with powerful sound, taking you into an exciting atmosphere. With a combined output of 880 watts and rich bass from a 10-inch subwoofer, the JBL Bar 1000 features MultiBeam™ technology and 4 top-firing speakers (2 on the soundbar and 2 on the removable wireless surround speaker). Deliver immersive Dolby Atmos® and DTS:X 3D surround sound with a spacious soundstage without additional wiring. The dialogue sound will remain crystal clear. You can stream your favorite playlists via AirPlay, Alexa MRM, and Chromecast built-in™ as if the artist were playing live right in front of you. Experience immersive entertainment in the comfort of your own living room.
generationBAR 1000Audio7.1.4 channelPower supply100 - 240V AC, ~ 50/60HzNetwork standby power< 2.0WOperating Temperature0°C - 45°C
Combined speaker output power880 wattsSoundbar speaker output power (Max @THD 1%)440 wattsOptional speaker output power (Max @THD 1%)70W x 2 pcsSubwoofer output power (Max. @THD 1%)300 wattsTransducer type in Soundbar5x (46x90) mm racetrack, 3x 0.75 in (20 mm) tweeter, 2x 2.75 inches (70 mm) full-range speakersTransducer type in auxiliary speaker0.75-inch (20mm) tweeter, 2.75-inch (70mm) full-range speakerTransducer type in subwoofer10 inches (260 mm)Frequency range33Hz - 20kHz (-6dB)Audio input channel1 Optical, Bluetooth, USB channel (supports USB playback only for US models. Other USB models are for service only.)
Soundbar size (WxDxD)1194 x 56 x 125 mm / 47" x 2.2" x 4.9"Soundbar main body (WxDxD)884 x 56 x 125 mm / 34.8" x 2.2" x 4.9"Optional wireless speaker size (per unit)(WxDxL)155 x 56 x 125 mm / 6.1" x 2.2" x 4.9"Subwoofer size (WxDxL)305 x 440.4 x 305 mm / 12" x 17.3" x 12"weight3.7 kg / 8.2 lbsWireless auxiliary speaker weight (per unit)1.4 kg / 3.1 lbsSubwoofer weight10 kg / 22 lbsPackage size (WxDxD)1000 x 375 x 475 mm / 39.4" x 14.8" x 18.7"Package weight19.4 kg / 42.7 lbs
USB PORTType AUSB POWER SUPPORT5V DC, 0.5ASupported file formatsMP3MP3 AUDIO CODECMPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3RANDOM RATE OF MP316 - 48 kHzBITRATE OF MP380 - 320 kpbsBluetooth version5.0Bluetooth profilesA2DP 1.2, AVRCP 1.5Bluetooth transmitter frequency range2400MHz – 2483.5MHzBluetooth is being transmitted.<15dBm (EIRP)Wi-Fi networksIEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)2.4G Wi-Fi transmitter frequency range2412 - 2472MHz (2.4GHz ISM band, USA 11 channels, Europe and others 13 channels)2.4G Wi-Fi transmission power< 20dBm (EIRP)5G Wi-Fi transmitter frequency range:5.15 - 5.35GHz, 5.470-5.725GHz, 5.725 - 5.825GHzPower of 5G Wi-Fi transmitter:5.15-5.25GHz <23dBm,5.25-5.35GHz & 5.47-5.725GHz <20dBm,5.725-5.825GHz <14dBm (EIRP)2.4G WIRELESS TRANSMITTER FREQUENCY RANGE:2406 - 2474MHzPOWER OF 2.4G WIRELESS TRANSMITTER:＜10dBm (EIRP）
HDMI VIDEO RECEIVER PORT3 ChannelsHDMI output information (with Enhanced Audio Return Channel, eARC)1 ChannelHDCP VERSION OF HDMI2.3THROUGH HDR PLAYBACKHDR10, Dolby Vision
1 x Soundbar Speaker2 x Detachable Wireless Extra Speaker1 x Wireless SubwooferRemote Control 2 x AAA batteries Power cord (up to 8 wires, depending on model)1 x HDMI cable2 x Wall mount bracket kit (for main Soundbar speakers) + 2 x Wall mount bracket kit (for optional speakers) with screws4 x Side coverBeginner's GuideSafety Manual and Warranty CardMold for wall mounting
